Wybierz częsci
| 1 | LID,LOCKER BOW F2J-U476A-00-00 ilość: 1 |
|
| 2 | CUSHION, RUBBER F1C-U5741-01-00 ilość: 5 |
|
| 3 | CUSHION, RUBBER F1T-U5741-00-00 ilość: 2 |
|
| 4 | SCREW,TAPPING 90167-08S08-00 ilość: 2 |
|
| 5 | SCREW, #6 X 1/2" 90167-06SA7-00 ilość: 4 |
|
| 6 | SCREW,TAPPING 90167-06S10-00 ilość: 1 |
|
| 7 | HINGE 5 F3F-U2826-10-00 ilość: 2 |
|
| 8 | SCREW, COUNTERSUNK 90161-08SA4-00 ilość: 10 |
|
| 9 | HATCH SUPPORT ASSY F1T-U2880-00-00 ilość: 1 |
|
| 10 | SCREW, TAPPING 90167-08SA9-00 ilość: 4 |
|
| 11 | LOCK ASSY. F3H-U5540-00-00 ilość: 1 |
|
| 12 | HATCH, FLOOR F2D-U5111-10-00 ilość: 1 |
|
| 13 | HINGE 5 F3F-U2826-10-00 ilość: 2 |
|
| 14 | SCREW,TAPPING 90162-10S10-00 ilość: 6 |
|
| 15 | SCREW,TAPPING 90162-10S10-00 ilość: 4 |
|
| 16 | LOCK ASSY. F3H-U5540-00-00 ilość: 1 |
|
| 17 | SUPPORT, HACH 2 F1C-U2896-10-00 ilość: 1 |
|
| 18 | BRACKET,HATCH SUPPOR F1C-U2899-00-00 ilość: 2 |
|
| 19 | SCREW, #10 X 1/2" 90167-10S08-00 ilość: 3 |
|
| 20 | SCREW, 10-24X3/4" 90157-10S12-00 ilość: 2 |
|
| 21 | WASHER, #10 FLAT 90201-10S00-00 ilość: 2 |
|
| 22 | NUT, 10-24 NYLOX 90185-10S00-00 ilość: 2 |
|
| 23 | PACKING 4 F2D-U266C-00-00 ilość: 1 |
|
| 24 | TANK HATCH ASSY F3H-U5106-10-00 ilość: 1 |
|
| 25 | PACKING 4-SHORT L=620MM F3H-U266C-00-00 ilość: 2 |
|
| 26 | PACKING 4-LONG L=1245MM F3H-U266C-10-00 ilość: 2 |
|
| 27 | LOCK ASSY F2D-U5540-11-00 ilość: 4 |
|
| 28 | BRACKET F2D-U4949-00-00 ilość: 1 |
|
| 29 | BRACKET F1T-U4949-01-00 ilość: 1 |
|
| 30 | SCREW, #10X1 1/2 90162-10S24-00 ilość: 6 |
